XSG Rotating Flash Dryer for Food Ingredient Processing: Corn Starch Powder
XSG Rotating Flash Dryer is evaluated for corn starch powder in food ingredient processing. The defined feed is washed and mechanically dewatered corn starch cake. Match this duty to the material checks below and the unchanged original equipment parameters.
Corn Starch Powder: Application and Process Requirements
For corn starch powder, avoid unintended gelatinization while dispersing wet starch lumps. Begin with washed and mechanically dewatered corn starch cake and confirm how the incoming grade varies before defining the drying cycle.
Feed, Product Quality and Downstream Handling
| Review item | Corn Starch Powder |
|---|---|
| Defined feed | washed and mechanically dewatered corn starch cake |
| Material-specific focus | avoid unintended gelatinization while dispersing wet starch lumps |
| Product checks | moisture, starch functionality, color and microbial criteria |
| Downstream handling | hygienic cooling before starch packing |
Material Movement and Drying Control
Include moisture, starch functionality, color and microbial criteria in the trial record. Fix the sampling locations and analytical methods before comparing trials; feed preparation and cooling can affect the measured result.
Drying Endpoint and Product Acceptance
After acceptance, arrange hygienic cooling before starch packing. Review discharge, temporary holding and packaging exposure as part of the moisture-control plan.
Application-Specific Equipment Selection
XSG Rotating Flash Dryer selection for corn starch powder starts with spin flash dryer requirements and the defined feed. Assess powder drying and Industrial drying equipment together with chemical dryers; the industrial food dryer duty must be demonstrated using representative material and the required finished-product specification.
View the XSG Rotating Flash Dryer range and original equipment specifications
Technical References for This Application
Define hygiene and contamination controls for the food process. FDA food manufacturing practices.
Review food-hygiene planning alongside the drying operation. Codex food-hygiene resources.
Evaluate the finished ingredient using the agreed water-activity method. FDA water-activity reference.
Review the dust characteristics of the collected dry material. HSE combustible-dust guidance.
Review the thermal duty and utilities for the actual feed. U.S. DOE process-heat reference.
Equipment Reference Parameters
These are the XSG Rotating Flash Dryer model specifications. The operating duty for corn starch powder must be established from the feed and the finished-product requirements above.
| Model | ID of Main Machine(mm) | Air Amount (m³/h) | Evaporated Moisture(kg) | Max. Equipped Capacity (kw) | Max. Height (m) | Occupied Area (m²) |
|---|---|---|---|---|---|---|
| XSG-2 | 200 | 350-500 | 12-17 | 6~10 | 4 | 15 |
| XSG-4 | 400 | 1150-2000 | 40-70 | 12~20 | 4.8 | 20 |
| XSG-6 | 600 | 2450-4500 | 80-150 | 24~40 | 5.8 | 28 |
| XSG-8 | 800 | 4450-7550 | 150-250 | 38~65 | 6.4 | 35 |
| XSG-10 | 1000 | 7000-12500 | 230-420 | 55~90 | 7.1 | 40 |
| XSG-12 | 1200 | 10000-18000 | 300-600 | 80~135 | 7.8 | 52 |
| XSG-16 | 1600 | 18000-30500 | 600-1000 | 160~270 | 8.5 | 80 |
| XSG-20 | 2000 | 50000-78000 | 1000~1500 | 250~430 | 10.1 | 150 |
| Name of raw material | Temperature of air heat (°C) | Primary moisture (%) | Final moisture (%) | Practical dry capacity (kg/h) |
|---|---|---|---|---|
| ZDC Accelerant | 150 | 60 | 0.5 | 80~110 |
| Oil Solve Ink | 150 | 45 | 2 | 350~380 |
| Silicinate Zinc Mararose | 120 | 30 | 1 | 120~150 |
| Pinhealing-yanin Dye | 150 | 55 | 1 | 160~180 |
| Calcium Citrate | 140 | 40 | 1 | 300~350 |
| Superfine Calcium Carbonate | 160 | 70 | 1.5 | 430~470 |
| Kurry Treatment Agent | 200 | 75 | 5 | 290~310 |
| Sodium Isocyanurate Dioxide | 180 | 25 | 0.2~2 | 80~120 |
| Sodium Isocyanurate Trioxide | 150 | 30 | 1 | 90~150 |
| Zinc Shemate | 150 | 80 | 0.5 | 140~160 |
| Aluminum Hydroxide | 180 | 55 | 1.5 | 250~280 |
| Zinc Carbonate | 150 | 80 | 1 | 130~170 |
| Insecticide | 120 | 30 | 1 | 80~110 |
| TMTD | 140 | 65 | 0.5 | 80~120 |
| DSD acid | 150 | 60 | 0.5 | 80~120 |
| Ferric oxide red | 200 | 60 | 0.5 | 300~350 |
| Antimony Dioxide | 180 | 45 | 1 | 280~320 |
| Cuprous Chloride | 200 | 20 | 3 | 290~310 |
| White Carbon Black | 280 | 85 | 5 | 250~300 |
| Selection Item | Information Required |
| Feed material | Composition, consistency and bulk density |
| Moisture | Initial moisture and target final moisture |
| Throughput | Required feed rate and finished product output |
| Temperature | Product temperature limit and available heating utilities |
| Powder | Required particle characteristics and collection method |
| Installation | Site dimensions, utilities and process connections |
| Material Group | Information for Assessment | Trial Review |
| Agricultural chemicals | Composition and handling requirements | Moisture removal and product properties |
| Ceramic materials | Feed consistency and particle requirements | Dispersion and collection |
| Food materials | Ingredient properties and cleaning scope | Temperature exposure and powder quality |
| Inorganic chemicals | Composition and compatibility | Drying behavior and collection |
| Organic chemicals | Material and vapor properties | Process suitability |
Discuss Corn Starch Powder Drying
Send QUANPIN the incoming corn starch powder specification, sample information and the required final product condition for an equipment review.
